Hakko Fume Extraction System w/Ducting

Hakko Fume Extraction System w/Ducting - FA430-KIT2

~~$831.87~~ $748.68

Description

The Hakko KIT2 Fume Extraction System delivers powerful, quiet, and efficient fume removal for soldering, manufacturing, and laboratory environments. Designed for operator safety and air purity, it features a dual-port ducting system with a three-stage filtration process that removes hazardous flux fumes, particulates, and chemical vapors at the source.

Engineered for precision workspaces, the KIT2 includes digital speed control, low-noise operation, and a filter-replacement indicator that ensures optimal performance. Its compact, ESD-safe housing makes it suitable for electronics assembly, cleanroom workstations, and ESD-controlled environments.

Whether you’re handling sensitive electronics, performing solder rework, or maintaining clean manufacturing zones, the Hakko KIT2 provides dependable, high-efficiency air filtration to protect your team and equipment.

Key Features

• 3-Stage Filtration System: Pre-filter, HEPA filter, and chemical (activated carbon) filter remove > 98% of particles ≥ 0.3 µm.

• Dual-Port Design: Supports one or two workstations simultaneously with included ducting.

• Adjustable Airflow: 145 CFM (single port) or 167 CFM (dual port) provides customizable extraction power.

• Digital Control Panel: Precise airflow adjustment and real-time filter monitoring.

• Quiet, Efficient Operation: Noise levels as low as 44 dB make it ideal for lab and assembly environments.

• Filter Life Indicator: Alerts users when filter replacement is required for continued efficiency.

• Compact & ESD-Safe: Designed for electronics and static-sensitive applications.

• Tool-Free Maintenance: Quick filter replacement and easy-access housing for simplified upkeep.

Applications

• Electronics Manufacturing & Rework: Removes flux fumes, solder smoke, and particulate matter from soldering stations.

• Laboratories & R&D Facilities: Ideal for chemical vapor and particulate capture during testing or fabrication.

• Cleanroom Environments: Maintains low particulate levels with ESD-safe performance.

• Optical & Medical Device Assembly: Ensures operator safety and contamination control.

• Educational & Technical Labs: Provides quiet, effective ventilation for multiple workstations.

• Repair & Maintenance Centers: Supports mobile or benchtop setups requiring localized fume extraction.

Benefits

• Improved Air Quality: Captures hazardous fumes and particulates directly at the source.

• Enhanced Safety Compliance: Meets OSHA and EPA guidelines for air filtration in soldering and lab environments.

• Operational Efficiency: Dual-port setup allows two operators to work simultaneously.

• Low Maintenance Costs: Long-life filters and simple replacement process reduce downtime.

• Quiet Performance: Maintains comfortable working environments without noise disruption.

• Durable Design: Built with Hakko reliability for long-term use in demanding conditions.

Product Specs

Power Consumption	110 W / 120 VAC
Motor Type	Brushless
Max Airflow (Single Duct)	4.1 m³/min (145 CFM)
Max Airflow (Two Ducts)	4.7 m³/min (167 CFM)
Vacuum Pressure	1500 Pa (0.44 in Hg)
Filtering Efficiency	>98% @ 0.3 µm (capable of 99.97% @ 0.3 µm)
Noise Level	44–53 dB @ 1 m
Dimensions	330 (W) × 366 (H) × 343 (D) mm, (13.0 × 14.4 × 13.5 in)
Weight	7.5 kg (16.5 lb)
ESD Safe	Yes
