Dow SYLGARD 160 Silicone Encapsulant Part A Gray 5.4 kg Pail - PF160AGL (MOQ/22)

$447.94
Add to wishlist
Add to compare
SKU: PF160AGL
California prop 65
Description
  • General-purpose potting. Dow SYLGARD 160 Silicone Elastomer is a two-component, room-temperature or heat-curing encapsulant used for general potting applications of power supplies. It has good flowability, moderate thermal conductivity, and flame resistance, and it is mixed at a 1:1 ratio. These items are a Dow product repackaged by KitPackers, an authorized repackager of Dow.
  • Where it is used. SYLGARD 160 is suitable as a general potting material for power supplies, connectors, sensors, industrial controls, and transformers. Its good flowability lets it fill around components and into assemblies, providing mechanical protection and electrical insulation for a broad range of electronics.
  • Cure and processing. As a two-part liquid kit, the components are mixed thoroughly and cure to a flexible elastomer well suited to protecting electrical and PCB assemblies. The material can cure at room temperature or be heat-accelerated for faster processing, giving flexibility to match production throughput.
  • Protection profile. The cured elastomer combines flame resistance with moderate thermal conductivity, helping protect potted assemblies against heat and ignition risk while insulating them from moisture and mechanical stress. Independent distributor data lists a UL 94 V-0 flammability rating for the material; users requiring formal agency approval should confirm current listings for their specific grade and application.

Recommended For

  • General potting of power supplies
  • Connectors and sensors
  • Industrial controls
  • Transformers
  • Electrical and PCB assemblies needing flame resistance

Available Variants

  • PF160AGL — Part A (gray), 5.4 kg pail
  • PF160BGL — Part B (off-white), 5.4 kg pail
  • The two pails are the matched components of one system: gray Part A and off-white Part B are combined 1:1 to form the cured encapsulant. Both parts are required to use the product, so they are ordered together rather than as alternatives.

Product Details

  • Product type: Two-part silicone potting encapsulant
  • Color: Part A gray; Part B off-white
  • Mix ratio: 1:1
  • Cure: Room temperature or heat cure
  • Key properties: Good flowability, moderate thermal conductivity, flame resistance
  • Flammability: UL 94 V-0 per independent distributor data (confirm current listing)
  • Packaging: Repackaged by KitPackers; Part A and Part B 5.4 kg pails

Primary Industries

  • Power supply manufacturing
  • Electronics and PCB manufacturing
  • Industrial controls and instrumentation
  • Transformer and connector manufacturing

Standards and Certifications

  • UL 94 V-0 flammability rating per independent distributor data (users should confirm the current agency listing for their grade)
Reviews

FAQs

What is SYLGARD 160 used for?

It is a two-part silicone encapsulant for general potting of power supplies and related electronics, including connectors, sensors, industrial controls, and transformers. Mixed 1:1 and cured, it provides mechanical protection and electrical insulation, combining good flowability with flame resistance and moderate thermal conductivity for a wide range of assemblies.

How is it mixed and cured?

SYLGARD 160 uses a simple 1:1 mix ratio of Part A to Part B and can cure at room temperature or be heat-accelerated for faster processing. The two liquid components are mixed thoroughly, then cure to a flexible elastomer. Consult the datasheet for pot life and cure times at your temperature.

Is SYLGARD 160 flame resistant?

Yes. Dow describes the material as flame resistant, and independent distributor data lists a UL 94 V-0 flammability rating. Because agency listings can vary by grade and change over time, users who need formal certification should confirm the current UL listing for their specific product and application before relying on it.

Why are the two parts different colors?

Part A is gray and Part B is off-white so the components can be told apart and their thorough blending confirmed during mixing. Both parts are required, since neither cures into the finished elastomer on its own. Combining them at the correct 1:1 ratio ensures proper cure and performance.

What does 'repackaged by KitPackers' mean?

These pails contain genuine Dow SYLGARD 160 that has been repackaged into these sizes by KitPackers, an authorized Dow repackager. The underlying material and its documented properties are the Dow product; KitPackers simply provides convenient container formats rather than altering the formulation.
